Green Die Springs

Green mold springs are high-performance elastic elements manufactured in strict accordance with Japanese Industrial Standards (JIS). Their green color indicates a "heavy load" rating, and they are designed specifically for heavy-duty molds and industrial equipment that require high load-bearing capacity and long-term stable operation.

We are not limited to standard specifications. With a deep understanding of material behavior under heavy-duty conditions, we are committed to providing reliable, custom-made, green mold spring solutions for key applications such as heavy-duty injection molding, precision stamping, and automated machinery. We are a solid support for your heavy-duty systems.

1. Materials:

Weuse imported alloy steel (such as 55CrSi) or, upon customer request, can select top-gradematerials such as Suzuki SWOSC-V from Japan

Mold springs made from ordinary 65Mn spring steel are prone to overheating, breakage, temper brittleness, and cracking; our mold springs are made from imported alloy steel, which has excellent high fatigue performance and good anti-relaxation properties.

High fatigue life:

Through precise calculations of the helix angle and optimized stress distribution design, our springs effectively avoid localized stress concentration during compression. Combined with a high-pressure processing technology, they can guarantee over 150,000 reliable compression cycles even under standard heavy-duty conditions, with stable spring force output and extremely low attenuation rate.

3. Excellent heavy-load stability and accuracy

Green mold springs are renowned for their high and stable stiffness coefficient. During long-term, continuous high-load operations, they maintain a precise force-displacement relationship, effectively reducing the risk of performance drift due to material fatigue, and providing durable, precise elastic support and dynamic buffering for heavy equipment.

Our green mold springs are widely used in fields with stringent requirements for load and lifespan due to their excellent heavy-duty capacity and operational stability.

Heavy-duty molding equipment: mold ejection, clamping and buffering systems for large injection molding machines and die casting machines.

Precision stamping and die systems: high-load reset and blanking mechanisms for precision stamping dies for automotive structural parts, electrical components, etc.

Industrial Automation and Heavy Machinery: Core load-bearing and vibration damping components for end effectors in automated production lines, heavy-duty presses, and packaging machinery.

High-end manufacturing equipment: constant force clamping and elastic compensation units for equipment such as CNC bending machines and heavy-duty fixtures.

V.JIS Standard Parameter Reference and Our Customization Value

Below are some typical parameters for JIS standard green mold springs (heavy load) for your initial selection reference. We can also accurately manufacture and supply these standard specifications.

 However, the real engineering challenges often begin "outside the standards".

Standard products may be ineffective in the following situations, which is where our customized services come in handy:

•Space constraints: The mounting holes are smaller than the standard outer diameter or have a special shape.

•Special travel: The required working travel is much greater than or different from the standard compression amount.

•Precise force matching: The load curve needs to perfectly match the motion of your mechanism.

•Extreme environments: Facing high temperatures, corrosion, high frequencies, or long lifespan requirements.

We are not just a manufacturer, but also your partner for flexible component solutions. Please provide your specific requirements (space, stroke, force, environment, lifespan), and our engineers will provide you with a free customized design draft and optimization suggestions.
